Flat Drip Irrigation Pipe Extrusion Plant
A complete high-speed production line for flat drip irrigation tape, combining a groove-fed extruder, servo inserting and punching units, and online auto-imaging monitoring for consistent dripper placement at wall thickness from 0.15mm to 1.1mm.
Overview
The Flat Drip Irrigation Pipe Extrusion Plant is engineered by Global Extrusion Technik (GET) for producing flat drip irrigation pipe used in agricultural and horticultural irrigation. The line combines a groove-fed extruder, servo-driven dripper inserting unit, and servo punching unit — all monitored by an online auto-imaging inspection system.
Available in four capacities — GET-90MPM, GET-120MPM, GET-150MPM and GET-200MPM — the plant is built to produce pipe with wall thickness from 0.15mm to 1.1mm and diameters of 12mm, 16mm and 20mm, at dripper sorting speeds of up to 600 pieces per minute.
The die head and calibrating unit are fully adjustable for thickness, and the haul-off speed synchronizes automatically with production requirements for stable, low-noise pulling.
Technical Specifications
| Models | GET-90MPM | GET-120MPM | GET-150MPM | GET-200MPM |
| Extruder Drive (kW) | 22KW–30HP | 30KW–40HP | 37KW–50HP | 55KW–75HP |
| Screw Dia (mm) | 65mm GF X 45mm X 30mm | 65mm GF X 45mm X 30mm | 65mm GF X 50mm X 30mm | 75mm GF X 50mm X 30mm |
| L/D Ratio | 33:1 | 33:1 | 33:1 | 33:1 |
| Inserting Servo Unit | 300 | 400 | 500 | 700 |
| Punching Servo Unit | 250–300 | 350–400 | 450–500 | 650–700 |
| Wall Thickness (mm) | 0.2 to 0.8 | 0.2 to 0.8 | 0.2 to 0.8 | 0.2 to 0.8 |
| Punching | Servo | Servo | Servo | Servo |
| Line Speed (MPM) (0.50) | 90 | 120 | 150 | 200 |
Features
Advanced Technology Design
Flat drip pipe making machines are designed with advanced technology and innovative features for reliable continuous production.
Flexible Pipe Sizing
Produces drip irrigation pipe with wall thickness of 0.15mm–1.1mm, in pipe diameters of 12mm, 16mm and 20mm.
High-Speed Dripper Sorting
Dripper sorting speed of up to 600 pieces per minute keeps pace with high-output production lines.
Synchronized Haul-Off
Haul-off speed can be synchronously adjusted according to production requirements, with stable, reliable, low-noise pulling.
Line Speed up to 200 MPM
The fastest configuration, GET-200MPM, runs at line speeds up to 200 metres per minute.
Auto Imaging Monitoring
Online auto imaging analysis and monitoring punching systems detect faults and trigger an automatic alarm function.
Adjustable Die Head
Extruder die head, calibrating unit and pipe thickness are all fully adjustable to your production spec.
High Daily Throughput
Per-day production ranges from 120,000 to 250,000 metres depending on the model selected.
